AIRCRAFT LCD Monitors MIL Certified Display

All of our Military COTS displays are flight certified or have been air qualified by our customers and are currently deployed on a variety of military aircraft. They are built to meet aerospace MIL Standard requirements for durability and reliability. Our aircraft LCD displays accept pressure gradients from sea level to 40,000 ft. LCD heaters permit reliable operation from -50C up to 70C. They have a compact, light design to minimize payload size and weight. All displays are tailored to meet shock and vibration profiles for large jets, small turboprops and helicopters.

Beechcraft_RC-12N_Huron
Rugged Display Product RFT2-2LH-17-USB-WS-R

C4ISR MC-12 TURBOPROP: RFT2-2LH-17-USB-WS-R

  • Rugged compact design stowes in 2U
  • Shock and Vibration for Turboprop Aircraft
  • Designed for Rapid Deployment
  • Flight Certified
Blackhawk
Rugged Display Products military certified display csc-17-cat5a-810-sk-MIL-cert

UH-60A BLACK HAWK HELICOPTER: CSC-17-CAT5A-810-SK

  • < 1mm backlash in any axis in extended, fully deployed position
  • Passed Shock and Vibration for Black Hawk Helicopter in Deployed Position
  • Unit Removable/Replaceable from Front in < 5 minutes
  • Zero backlash cable management system
  • Flight Certified
Refueling-Tanker
Rugged Display Products RFT2-17-SKB-HTR

KC-135 REFUELING TANKER (ROBE): RFT2-17-SKB-HTR

  • Explosion proof: iaw RTCA/DO-160D paragraph 9.3.2 for Explosive Atmosphere, (Ambient pressure, 50C).
  • Vibration per MIL-167-1
  • Shock per MIL-STD-810
  • MIL-STD-461 EMI
  • LCD Heater for rapid warming from -45C cold storage in five minutes
  • Flight Certified
CSC-17-CAT5A-810-SK Rugged Military Monitor

CSC-17-CAT5A-810-SK

Certified MIL-810 and -461 MIL-STD-1275/-704 Compliant• 17" Military Certified KVM
• 1200 nit cd/m2 LCD, 4-Port CAT5 Switch
• Deployed on UH-60 Blackhawk

Rackslide Pull-Out Rugged KVM Display

CSC-17-VGA-SK

• 17.0” Diagonal
• 1280 x 1024 (SXGA); 5:4 AR
• MIL-STD-810F (Helicopter)

RF-17W-461-28

RF-17W-461-28

• 17" 1920x1200 LCD
• MIL STD Compliant
• USN Air Qualified, 28VDC

RF-20-R-PIP-28-V2

RF-20-400-PIP

• 20.1" 1600x1200 LCD
• Built with MIL-SPEC compliant parts
• Flight Certified USN Aircraft

RF-20-DC-461

RF-20-DC-461

• 20.1" 1600x1200 LCD
• 28VDC Power Operation
• Deployed USAF MC-12

RF-20-RC-T2

RF-20-RC-T2

• 20.1" 1600x1200 LCD
• Air Qualified on E6B
• Certified to MIL-461 and -810

RF-20-R-PIP-28-V2

RF-20-R-PIP-28-V2

• 20.1" 1600x1200 Touchmonitor
• Dual Hi-Brite/NVIS Backlight
• Air Qualified, 28V Operation

PM-10.4-MFD

PM-10.4-MFD

• 10.4" Air Qualified XGA MFD
• Dual Hi-Brite/NVIS Backlight
• 28 Programmable Buttons

PM-17-R rack and panel mount display

PM-17-R

• 17" Air Qualified Touchmonitor
• DO-160 Certified Fixed Wing
• Built with MIL-SPEC compliant parts

PM-30-PIP-28

PM-30-PIP-28

• 30" 2560x1600 WQXGA LCD
• DVI, 3G-SDI, PIP, 28VDC
• DO-160 & MIL-461 Certified

Get The Display You Need

custom lcd touch screens
Click Here

WHEREVER YOU DEPLOY, WE'RE ALREADY THERE

RUGGED MILITARY AND INDUSTRIAL DISPLAY MONITORS

(click on the deployments below to see examples of application)

control station Navair-ATC rugged display
Sea Marine LCD Monitors Qualified for Ships & Submarines
Ground Mobile LCD Monitors for Vehicles
Control station MQ-1_Predator_unmanned rugged LCD display
Rugged INDUSTRIAL LCD Monitors
control station Navair-ATC rugged display
Sea Marine LCD Monitors Qualified for Ships & Submarines
Ground Mobile LCD Monitors for Vehicles
Control station MQ-1_Predator_unmanned rugged LCD display
Rugged INDUSTRIAL LCD Monitors

MANY OF OUR RUGGED DISPLAYS ARE ALREADY CERTIFIED AND QUALIFIED ON MILITARY & INDUSTRIAL PROGRAMS

Don’t See Exactly What You Need?

All of our displays are available with various options and configurations. We can modify or design a display with the unique features you require.

See our standard options and send us a list of your requirements, or contact us today for a custom configuration quote.
